Servo Feeder

Servo Feeder

Casa Grande, AZ

orCall 1-520-836-9727

Description

One (1) Used 15" x 10 Ga. x 5,000 lb. Rowe / Egan Combination Press Feed & Cut-To-Length Line; Servo Driven; Record #3666 Specifications: Capacity:       Maximum Stock Width............................ 15" @ 10 ga. (nominal)      Minimum Stock Width................ ............. 3" (nominal)      Maximum Stock Thickness....................... 0.120" @ 14" wide      Maximum Coil Weight............... .............. 5,000 lbs.      Maximum Coil Outside Diameter..............65" (nominal)      Coil Inside Diameter................................. 16" - 21" (nominal) Number of Straightener Rolls......................... 3 over 4 Size of Straightener Rolls............................... 2.000" dia. x 15" long Number of Feed Pinch Rolls.......................... 2 Size of Pinch/Feed Rolls................................. 4.000" dia. x 20" long Feed Length..................................................... 0" - 999" (max) Feed Rate (Variable)........................................ 10-45 F.P.M. (max) Feed Direction.................................................. (to be determined) Pass Line Height............................................... 36” - 48" (nominal) Cradle / Straightener Drive............................... 2 HP Variable Speed Servo Drive System.......................................... 1.5 HP / 1200 Watt Hydraulic System.............................................. 5 HP (nominal) Electrical Characteristics.................................. 240/480 VAC / 3 Phase / 60 Cycle Equipped With: 5,000 lb. x 15" Rowe Coil Cradle / Straightener Unit with Looping Control. 20” x 10 Ga. Egan Servo Driven Roll Feeder

8 ft. Discharge Stacker. Approx. Overall Dimensions.............27' L-R x 4' F-B x 5' High Weight.................................7,000 lbs. (est.) FOB................Casa Grande, AZ.

Specifications

ConditionUsed
Stock Number3666
