50 Ton Greenerd C-Frame Hydraulic Press; 20'' x 26'' bed; 40'' Str, 48'' D.L.O #2225

Sold

50 Ton Greenerd C-Frame Hydraulic Press; 20'' x 26'' bed; 40'' Str, 48'' D.L.O #2225

Location:Casa Grande, AZ

Description

(1) Used 50 Ton Greenerd Model H-50-35LS8 C-Frame Hydraulic Press; S/N 66K8032 Specifications: Capacity........................50 Ton Bed Area........................38" L-R x 16" F-B Slide Area......................38" L-R x 16" F-B Bed Opening.....................5" L-R x 12" F-B Stroke..........................40" Daylight Opening................46" (nominal) Distance Bed to Floor...........37" Tie Rod Diameter................ Number of Ram Cylinders......... Type of Ram Cylinders........... Diameter of Ram Cylinders....... Ram (Slide) Speeds: Pressing................... Advance.................... Return..................... Hydraulic System: Manufacturer & Type........ Power & Pressure...........10 HP Fluid Capacity.............125 gallons Electrical Characteristics......208/220/440 VAC / 3 Phase / 60 Cycles Equipped With: 10 HP Complete Hydraulic system w/ Reservoir Operator's Lever/ Foot Controls Adjustable Limit Switches Complete Electrical Controls Overall Dimensions..............40" L-R x 80" F-B x 145" High Weight..........................15,000 lbs. (est.) F.O.B...........................Casa Grande, Arizona

Specifications

ConditionUsed
Stock Number2225
