Tannewitz G1 Vert. Band Saw

Specifications:

Blade Speed............................____ SFM

Blade Tension Control..................MANUAL

Size, Wheel Diameter...................36”

Under Guide Capacity...................

Throat Capacity........................36”

Base Construction......................CAST

Band Width Capacity....................1.75-2”

Band Length............................

Table Size.............................36”x37”

Auxiliary Table Size...................NA

Table Tilting..........................YES

Upper Wheel Adjustment.................MANUAL

Wheel Type.............................STAMPED STEEL

Gear-Adjusted Guide Post...............

Table Height...........................40”

Horsepower.............................1.5HP

Motor Drive............................BELT

Electrical Characteristics.............220/440 4.48/2.24 AMPS

3 PHASE 60HRZ
